QSC I/O-11NE
QSC I/O-11NE Versatile Q-SYS I/O–Network Interface
Q-SYS accessory panel, with isolated microphone input, 2 «speaker and display with timer monitor (I / O-22 NOT included).
Q-SYS I / O peripherals help connect the power of the Q-SYS Core processor to the outside world of audio. The I / O cards provide connectivity to analog and digital sources and destinations, while the I / O frame and I / O-22 allow local or remote inputs or outputs anywhere a standard Gigabit Ethernet network is available with connectivity back to the core.
I/O Frames can be used to physically locate inputs and outputs connections near their sources and destinations. Dual Gigabit Ethernet connections route the audio signals through the Core for processing. Each I/O Frame can house up to four I/O cards enabling up to 16 channels of input and/or output in a single unit.
Microphone/Line level input card:
|
Line level output card:
|
QSC DataPort I/O and instrumentation card:
|
AES/EBU input/output card:
|
- 2 «Speaker
- Screen With Timer Monitor
