Muxlab MUX-500754
The HDMI over IP PoE Extender allows HDMI equipment to be connected to create a Video Wall of a user configurable size (X by Y) supporting 100’s of screens, depending on network bandwidth, utilizing one receiver for each display in the array.
The transmitter unit is connected using a LAN switch (PoE or non-PoE), with maximum distances of 330ft (100m) of Cat5e/6 cable between equipment.
Set-up and configuration of the video wall function is carried out using the MuxLab ProDigital Network Controller (500811) – sold separately.
- Configure a Video Wall array with 100’s of displays, depending on network bandwidth
- HDMI 1.3
- Supports up to 1080p resolutions
- Visually lossless video (1 frame latency)
- Supports point-to-point, point-to-multipoint and multipoint-to-multipoint applications
- Transmission up to 330ft (100m) over Cat5e/6
- Transmission up to 390ft (120m) between one (1) TX and one (1) RX when no LAN switch is used in a point-to-point scenario
Applications:
- Digital signage
- Control room applications
- Medical imagery
- Retail
- Hospitality / entertainment displays
