Muxlab MUX-500718
The 12G-SDI 1×6 Splitter, 4K/60 (500718) allows one 12G/6G/3G/HD/SD-SDI source to be distributed and amplified to up to six 12G/6G/3G/HD/SD-SDI displays. The splitter supports up to 4K (3840 X 2160) video and HD audio, including 480i (SD-SDI), 720p/1080i (HDSDI), 1080p (3G-SDI), 4K/30 (6G-SDI) and 4K/60 (12G-SDI). The device automatically detects the 12G/6G/3G/HD/SD-SDI signal and re-clocks and regenerates the signal at the output for extending distances between source and displays. Additionally, all connectors are on the rear panel for neater cabling.
Applications:
Video production
Post production
Broadcasting
Studio to Studio
Live event
Mobile video
Medical imaging display
Features
- Distribute one 12G-SDI source to six displays
- Supports up to 4K @ 60Hz, including 12G/6G/3G/HD/SD-SDI
- Automatically detects re-clocks and regenerates the 12G/6G/3G/HD/SD-SDI signal
- LED diagnostic
- Connectors on rear for neater cabling
Specifications
- Environment: 12G-SDI, 6G-SDI, 3G-SDI, HD-SDI & SD-SDI.
- Devices: Camera, projectors, monitors, TV.
- Transmission: Transparent to the user.
- Detection: Auto Detection of the 12G/6G/3G/HD/SD-SDI Signal.
- Bandwidth: 11.88Gbps & 11.88/1.001Gbps
- Data Rates: 1.485, 2.97, 5.96 & 11.88 Gbps
- Output Impedance: 75Ω
- Signals: SDI protocol.
- Supported Resolution:
- 12G-SDI: 2160p50/59.94/60Hz (4:2:2)
- 6G-SDI: 2160p23.98/24/25/29.97/30Hz (4:2:2)
- 3G-SDI: 1080p50/59.94/60Hz (4:2:2)
