Muxlab MUX-500713
The MuxLab 500713 12G-SDI Fiber Extender Kit allows 12G-SDI to be transmitted up to 33,000ft (10km) via a one singlemode fiber cable in a point-to-point configuration at all specified bit rates.
The 12G-SDI Fiber Extender Kit supports transmission of up to 12 Gbpsof digital video within television broadcasting facilities and between professional video equipment.
- Supports 12G/6G/3G/HD-SDI signals
- Supports up to 4K/60 video
- Extend transmission up to 6.2mi (10km) over singlemode fiber
- LED diagnostics
Features
Specifications
- Environment: SDI single coaxial link: 12G, 6G, 3G, HD & SD.
- Devices: Monitors or any equipment supporting 12G, 6G, 3G, HD & SD single coaxial link.
Standards Supported
- 12G-SDI: SMPTE ST2082-2
- 6G-SDI: SMPTE ST2082-1
- 3G-SDI: SMPTE 424M
- HD-SDI: SMPTE 292M; SD-SDI : SMPTE 259M
- Bit Rates: 11.88Gb/s, 5.94Gb/s, 2.97Gb/s, 1.485Gb/s & 0.27Gb/s (automatic selection).
- Indicators: Power. Signal (signal present).
