Muxlab MUX-500506
The DisplayPort 1.2a 1×2 Hub, MST is a device that allows you to extend different DisplayPort 1.2a content from one DisplayPort connector to two monitors. The hub supports video resolutions up to 4K and PCM Audio up to 7.1-Channel and up to 192 kHz sampling rate, and supports Multi-Stream Transport (MST) of up to eight streams
Typical Applications:
- Commercial and residential AV systems
- Classroom training systems
- Digital signage
- Boardroom systems
- Collaborative PC systems
FEATURES
- Extend different DisplayPort 1.2a content from one DisplayPort connector to two monitors
- Supports data rate of 5.4 Gbps per lane with a total of 21.6 Gbps link rate
- HDMI link rate: 3.2 Gbps/data pair
- Supports dual mode DisplayPort
- 4K at 60Hz, 24 bits/pixel in DP 1.2a configuration
- 1080p at 240Hz, 24 bits/pixel
- Supports Multi-Stream Transport (MST) of up to eight streams.
