• Small, Unobtrusive Size
• High-Fidelity Sound for Subwoofer-Satellite Systems
• Elegant industrial design fits any décor

Specifications

Frequency Range  140 Hz – 20 kHz

Power Rating  IEC System Long-Term Ratings (low-Z direct): 30 Watts Continuous Program Power 15 Watts Continuous Pink Noise (60W peak), 100 hr

Sensitivity  82 dB (1kHz – 16 kHz)

Drivers  60 mm (2.5 in)

Coverage Angle  160° conical

Impedance  16 ohms

Input Connectors  Two removeable locking 2-pin connectors with screwdown terminals.

Optional Accessories  MTC-RAIL tile rails MTC-42NC New Construction bracket MTC-42MR Mud Ring Construction Bracket

Included Accessories  C-ring support backing plate, knockout strain relief, cutout template, paint shield.

Dimensions (Diameter x Depth)  127mm Diameter x 94mm Diameter Depth (5.0 in x 4.2 in)

Maximum SPL (1m)  94 dB (low-impedance,114 dB peak)

Color  White

Safety Agency  Suitable for use in air handling spaces per UL1480, UL2043, NFPA90 & NFPA 70. S7232/UL Listed, Signaling Speaker. Transformer UL registered per UL1876. In accordance with IEC60849/EN60849.

Backcan  formed steel (included «blind-mount»)

Baffle/Rim  ABS baffle with UL94-V0 flame class fire rating.

Plenum Usage  Yes, backcan included
