• Unique Nested Chamber™ design and Linear Dynamic Aperture™ port design delivers high output from a compact enclosure.
• JBL’s exclusive SonicGuard™ overload protection allows higher operational levels and improved
  system reliability.
• Component: Long excursion 200 mm (8 in) driver.
• Packaged with grille, backcan and tile rails for fast installation and easy stocking.
• Simple installation and wire connection method.

Specifications

Frequency Range  42 Hz – 200 Hz

Power Rating  See transformer taps

Transformer Taps  75W, 30W, 15W (& 7.5W @ 70V)

Coverage Angle  180° conical

Maximum SPL (1m)  108 dB (70V/100V, center of ceiling)
114 dB (70V/100V, near corner)

Nominal Impedance  8 ohms

Drivers  200 mm (8.0 in) subwoofer

Enclosure Material  Backcan: Formed steel Baffle/Rim: Medium impact polystyrene, fire rated UL94V-0

Input Connectors  Removable locking connector with screw-down terminals.

Safety Agency  Suitable for use in air handling spaces per UL1480, UL2043, NFPA90 & NFPA 70. S7232/UL Listed, Signaling Speaker. Transformer UL registered per UL1876. In accordance with IEC60849/EN60849.

Outside Dimensions (H x Dia)  345 x 345 mm (13.6 x 13.6 in) 318 mm (12.5 in) front of ceiling tile to back of backcan

Ceiling Cutout Size  305 mm (12.0 in) diameter (cardboard cutout template included)

Net Weight (each)  6.3 kg (14 lb)

Shipping Weight (pair)  14.3 kg (32 lb)

Included Accessories  C-shaped support backing plate 2 tile support rails (fits both 2 x 4 ft or 600 x 1200 mm tiles) Cutout template Paint shield Removable locking wiring connector

Sensitivity  95 dB SPL in ceiling near corner,
89 dB in center of ceiling

Backcan  formed steel (included «blind-mount»)

Baffle/Rim  Medium impact polystyrene, fire rated UL94V-0

Plenum Usage  Yes, backcan included
