Symetrix xIn
Symetrix xIn
Expand Analog I/O Using Dante. For use with Symetrix Radius, Prism and Edge DSPs, the Symetrix Dante I/O Expanders use Composer for setup. Using Composer eliminates switches, circuit board jumpers, and mechanical adjustments as well as the need for third party software applications.
- Designed for Use with Symetrix Dante-enabled DSPs
- Software Setup Using Composer
- Low Cost Way to Increase System Analog I/O Capacity
- Ultra Low Latency – No Audible Delays
- Top of the Line Specification
- 1/2 Rack Form Factor.
- PoE – injectors included.
- xIn 4 – 4 analog mic/line inputs.
- xIO 4×4 – 4 analog mic/line inputs + 4 analog outputs.
- xOut 4 – 4 analog outputs.
- Optional rack and surface mounting kits sold separately.
Analog Inputs
| Frequency Response | 20 Hz – 20 kHz, ± 0.5 dB. |
| Channel Separation | > 111 dB @ 1 kHz, +24 dBu. |
| Connectors | 3.5 mm Phoenix® connectors. |
| Number of Inputs | Four (4) switchable balanced mic or line level. |
| Nominal Input Level | +4 dBu with 20 dB of headroom. |
| Maximum Input Level | +23 dBu. |
| Mic pre-amp gain | 0, 11.8, 24, 44 or 54 dB switchable. |
| Mic pre-amp EIN | < -127dB with 150 ohm source impedance. |
| CMRR | > 76 dB @ 1 kHz, unity gain. |
| Input impedance | 8k Ohms balanced, 4k Ohms unbalanced. |
| Phantom power (per input) | +48 VDC @ 10 mA maximum. |
| Dynamic range | > 116 dB, A-weighted. |
| THD + Noise | < -100 dB, unweighted; 1 kHz @ +22 dBu with 0 dB gain. |
| Latency | 0.28 mS. |
